| 90度尼龙快插接头 | 90d Angle Nylon Fast Union Conduit Fittings | ||||
| 材 质： | 尼龙66 | Material: | Nylon 66 | ||
| 颜 色： | 黑、灰 | Color: | Black、grey | ||
| 防火等级： | UL94V-2 | Fire-protection class: | UL94V-2 | ||
| 防护等级： | IP54 | Protection rating: | IP54 | ||
| 耐温范围： | -40℃ - +115℃ | Temperature range: | -40℃ - +115℃ | ||
| 型号 Part No. | 螺纹标准 | 适配软管 | 外径（mm) | 内径（mm) | |
| 黑Black | 灰Grey | Thread Type | Conduit Size | I.D. | I.D. |
| DRIB-AM12 | DRIG-AM12 | M12x1.5 | AD10.0 | 12.0 | 8.0 |
| DRIB-AM12-1 | DRIG-AM12-1 | M12x1.5 | AD13.0 | 12.0 | 8.0 |
| DRIB-AM16 | DRIG-AM16 | M16x1.5 | AD13.0 | 16.0 | 12.0 |
| DRIB-AM16-1 | DRIG-AM16-1 | M16x1.5 | AD15.8 | 16.0 | 12.0 |
| DRIB-AM18 | DRIG-AM18 | M18x1.5 | AD15.8 | 18.0 | 14.0 |
| DRIB-AM20 | DRIG-AM20 | M20x1.5 | AD15.8 | 20.0 | 15.5 |
| DRIB-AM20-1 | DRIG-AM20-1 | M20x1.5 | AD18.5 | 20.0 | 15.5 |
| DRIB-AM24 | DRIG-AM24 | M24x1.5 | AD21.2 | 24.0 | 17.0 |
| DRIB-AM25 | DRIG-AM25 | M25x1.5 | AD18.5 | 25.0 | 18.0 |
| DRIB-AM25-1 | DRIG-AM25-1 | M25x1.5 | AD21.2 | 25.0 | 18.0 |
| DRIB-AM25-2 | DRIG-AM25-2 | M25x1.5 | AD28.5 | 25.0 | 18.0 |
| DRIB-AM27 | DRIG-AM27 | M27x2.0 | AD28.5 | 27.0 | 22.0 |
| DRIB-AM32 | DRIG-AM32 | M32x1.5 | AD28.5 | 32.0 | 24.0 |
| DRIB-AM32-1 | DRIG-AM32-1 | M32x1.5 | AD34.5 | 32.0 | 24.0 |
| DRIB-AM36 | DRIG-AM36 | M36x2.0 | AD34.5 | 36.0 | 29.0 |
| DRIB-AM40 | DRIG-AM40 | M40x1.5 | AD42.5 | 40.0 | 32.0 |
| DRIB-AM50 | DRIG-AM50 | M50x1.5 | AD54.5 | 50.0 | 39.0 |
| DRIB-AM63 | DRIG-AM63 | M63x1.5 | AD54.5 | 63.0 | 53.0 |
| DRIB-APG7 | DRIG-APG7 | PG7 | AD10.0 | 12.5 | 8.5 |
| DRIB-APG9 | DRIG-APG9 | PG9 | AD13.0 | 15.2 | 12.0 |
| DRIB-APG11 | DRIG-APG11 | PG11 | AD15.8 | 18.6 | 15.5 |
| DRIB-APG13.5 | DRIG-APG13.5 | PG13.5 | AD18.5 | 20.5 | 17.0 |
| DRIB-APG16 | DRIG-APG16 | PG16 | AD21.2 | 22.5 | 18.0 |
| DRIB-APG21 | DRIG-APG21 | PG21 | AD28.5 | 28.3 | 24.0 |
| DRIB-APG29 | DRIG-APG29 | PG29 | AD34.5 | 37.0 | 32.0 |
| DRIB-APG36 | DRIG-APG36 | PG36 | AD42.5 | 47.0 | 36.5 |
| DRIB-APG48 | DRIG-APG48 | PG48 | AD54.5 | 59.3 | 48.5 |
